Push Locking IP68 10A Waterproof Connectors 5 Pin AC Power Socket CCC Compliant

Name: Push Locking IP68 10A Waterproof Connectors 5 Pin AC Power Socket CCC Compliant
Brand: Jnicon
Price: 1 USD

Brand Name : Jnicon

Model Number : M16

Certification : TUV,UL,CE,CCC

Place of Origin : Shenzhen,China

MOQ : 100 (10 Pairs of samples)

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 10000 sets/Day

Delivery Time : 3~5 working days

Packaging Details : 1.Plastic bag;2.Carton;3.As per customer's requirements

Brand : Jnicon Connector

Structure : Screw Locking

Contact Pin : 5Pin Cable to Cable

Protection level : IP68

Material : PA66

Contact / Terminal Material : Gold Plated Brass

Contact Now

Push Locking 2Pin Power Jnicon Connector 3Pin Data Waterproof IP68 Connectors

Description of Jnicon Push Locking Waterpoof Connectors

5 Pin Ac Power Socket
Industrial Electrical Plug socket
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
circular waterproof connector
m16 industrial connector

Technical Parameters
Contact Resistance	10 mΩ max
Insulation Structure	500 MΩ at 500VDC
Operating Temperature	-40°C ~ +105°C
IP Class	IP67 (1m / 30min)
Mold Material	PA66
Contact/Terminal Material	Gold Plated Brass
Seal Material	Silicone

Application industries

Communications Application
product coding machines
inventory product coding
industrial inkjet equipment
Electric power equipment
Laboratory forensic&pathology equipment
Communications equipment
Heavy machinery

Operation Parameters
Voltage Rating	300VAC max
Current Rating	10A max
Min Wire Size OD	3.0mm ~ 5.0mm
Max Wire Size OD	6.5mm ~ 9.0mm
Max.Cable Cross Section Area	0.5mm2 ~ 1.5mm2

M16 3pin male plug female socket is a good connection model, widely used in LED lighting, especially in outdoor application, even underwater.

FAQ

1. Q: What type waterproof connector do you have?
A: We have 17series type connector,and make more than 3000types waterproof connector cable.Most of our connector is customized.We foucs on LED Waterproof connector,Assembly waterproof connector,Over-mold waterproof connector,T waterproof connector,Y customized waterproof connector.

2. Q: How to buy your products?
A: You need to do as followings:
* Confirm Current Rating and Number of Contacts
* Confirm Assembly style
* Confirm Cable Wire guage
* Confirm Cable Length and shipping way
